Lay Flat Main Line Hose is a crucial part to any pumping operation. Achieving higher Gallons Per Minute, while avoiding Friction Loss can save you hours in the field each year. Check out the different sizes that we offer. All of our new ZY Fire Lay Flat Hose includes a 5-year Warranty covering Materials and Workmanship.
| 6" Polyurethane Hose | 250 / 750 PSI | 660' Length |
| 8" Polyurethane Hose | 200 / 600 PSI | 660' Length |
| 10" Polyurethane Hose | 200 / 600 PSI | 660' Length |
| 12" Polyurethane Hose | 150 / 450 PSI | 660' Length |
| 12" Polyurethane Hose | 200 / 600 PSI | 660' Length |
This Spring 2020 marks the “New Breed” of Drag Hose by ZY Fire. A New Yarn Liner has been developed to allow better penetration and placement of the Polyurethane. The result is quite impressive by creating more adhesive quality and up to 50% more adhesion than the competition. Say “Hello” to the industry leader.
| Diameter (Inches) | Wall Thickness (Inches) | Burst Pressure (BAR/PSI) | Lbs/Ft | Tensile Strength (Lbs) |
| 5" Polyurethane Drag Hose | 0.17 | 32/480 | 1.34 | 43000 |
| 5.5" Polyurethane Drag Hose | 0.17 | 30/450 | 1.67 | 47500 |
| 6" Polyurethane Drag Hose | 0.18 | 30/450 | 2.22 | 55500 |
| 7" Polyurethane Drag Hose | 0.18 | 30/450 | 2.55 | 68000 |
ZY Fire is the largest “Through the Weave” hose manufacturer in the world
Founded in the year 2000, ZY Fire has become the leader by their dedication to the craft, quality control, technological superiority, and never taking shortcuts in production
Every Hose is tested (not just periodic tests) to assure the end-user, there are no surprises when the hose is deployed and put into service
ZY Fire’s hose manufacturing operation is a well-oiled machine with 12 Senior Engineers
Every hose has a Serial Number and Assurance of Quality
Over 300 Employees
Over 150,000 Square Meters of Manufacturing Space
200 Production Lines
Operating 24 hours per day, 7 days a week
With the technology ZY Fire has available, any Task or Hose achievable. Take for instance a client in the Oil and Fracking business. In the past, ZY Fire developed a Lay Flat Hose using Kevlar to resist punctures in the hose. Problem solved!
With all these Quality and Technological Features, you’d expect to pay a lot more for ZY Hose. Call us for pricing and request a quote you’ll be surprised at what quality costs.
The New ZY Drags are doing an outstanding job. Operators are noticing things such as:
No stretch and Pull Back at the end of a pull
The New ZY Drag hose is showing more expansion in diameter, resulting in more Gallons Per Minute
The Drag is very flexible no kinks when turning on the end of a pull
No Kinking back at the Loop when Pulling
ZY Fire has the Technology to place the Polyurethane where it’s needed most. For instance, in our Drag Hose ZY Fire, places more Polyurethane on the Exterior or the Drag Hose than on the interior. This assures a Longer Wearing Hose and NO Snaking under pressure.
Did you know that Friction Loss in your Main Line or Drag Hose can cost you efficiency, time, and dollars? Take a look at this chart below. Your pump gives you so much energy (GPM/PSI) How you use it makes all the difference. Questions? Call and we will be glad to answer them!
| Hose Dia. | 1,000 GPM | 1,500 GPM | 2,500 GPM | 3,000 GPM |
| 5" | 36 PSI Per 660' | 75 PSI Per 660' | 195 PSI Per 660' | 273 PSI Per 660' |
| 5.5" | 22 PSI Per 660' | 47 PSI Per 660' | 122 PSI Per 660' | 171 PSI Per 660' |
| 6" | 15 PSI Per 660' | 31 PSI Per 660' | 80 PSI Per 660' | 112 PSI Per 660' |
| 7" | 7 PSI Per 660' | 15 PSI Per 660' | 38 PSI Per 660' | 53 PSI Per 660' |
| 8" | 3 PSI Per 660' | 8 PSI Per 660' | 20 PSI Per 660' | 28 PSI Per 660' |
| 10" | N/A | 3 PSI Per 660' | 7 PSI Per 660' | 9 PSI Per 660' |
| 12" | N/A | N/A | 3 PSI Per 660' | 4 PSI Per 660' |
